RaceGrade TC8

RaceGrade TC8 - Discontinued

E888 Expander - Alternate

The RaceGrade TC8 is a CAN based device that reads up to (8) thermocouple temperature sensors, typically used for exhaust gas temperature measurement.

Features

• Small, lightweight & compact package
• Easy to adapt and wire into any vehicle, just 4 wires; power, ground, CAN high and CAN low.
• Built in amplifiers for up to 8 channels
• Splash protection, but not waterproof

Specifications

• Input Temp Range: 0 to 1000*C
• Thermocouple Style: K-type only
• Operating Voltage Range: 6 to 24vDC
• Operating Current Draw: < 0.1 Amps
• Operating Temp Range: -40*C to 120*C
• Dimensions: 3.5"x2.26"x1.0"
• Weight: 173 grams
• Mating Connector: ASL606-05SN

Utilize the drop down menus to complete your TC8 kit.

• Modification This option allows you to specify if you'd like a terminating resistor placed inside the case. The TC8 is commonly found at the end of the CAN bus, which will require this depending on the overall bus topology.
• Mating Connector & Boot Adds the correct mating connector and your choice of a straight or 90º Raychem shrink boot

Additional Items

• EGT Probe w/ Bung - We also offer Race Grade Thermocouple Sensors in 1/8" and 1/4" sizes, order individually.  Links for sensors and bungs on our site below.
• EGT PROBE
• EGT BUNG

** DISCONTINUED AS OF 11/24/24 **
