MSEL High Amp Flanged M6 Bulkhead Stud for Fuel Tanks

Bulk head stud for passing power through a bulk head or fuel tank.

• Max 25 Amps continuous per terminal (+5 AMP < 30 Sec) through a plastic bulkhead
• Delrin plastic insulator
• Viton o rings
• 14mm socket can be used on the electrical isolator.
• You can use these Bulkhead Fittings for Fuel Level Sensors or other electrical controls.
• The minimum bulkhead thickness is 1.5mm. Maximum Thickness of 9mm
• E85 Compatible
• Specifically designed for use with OEM style plastic fuel pump bulkheads

Ideal for providing power to submersible pump(s)

Includes carbon grease - please refer to diagram below for where to apply.

Please note, that these are sold as each. If you need a pair, please order 2.

Hex cup enables insulating sealing cups to be torqued up against each other ensuring a tight seal eliminating bad resistance resulting in excessive heat from high amperage.
